Wireless Modem Kit

Allows Maximum Operating Distance for Operations Display

Wireless Modem Kit

This optional wireless modem pair allows wireless communication between the iBOS System Controller and the Operations Display.   By using the Wireless Modem Kit you can mount the Operations Display up to 1,000 feet (304 meters) from the System Controller, which is ten times greater than the distance that can be obtained by using data cable.

  • No cables to run.
  • 1,000 feet (304 meter) range between System Controller and Operations Display.
  • USB connections to System Controller and the Operations Display.
  • No programming needed.
  • Easy to install.

Dimensions (shipping): 17.25"H x 11.75"W x 3.5" D (19.05 cm H x 25.4 cm W x 8.89 cm D)

Weight:  4.0lbs. (1.8kg)

Input Voltage: 100-240 VAC 50/60 Hz

Power Usage: 0.5 A / unit (max)

Output Voltage: 9.0 VDC/ 1.11A

Power cord length: 6.0 Ft (1.83 m)

Notes:  RF communication device that operates on 900MHz frequency hopping.
